The Janisol folding partition, built on the thermally insulated Janisol system, offers versatile functionality. It can serve as a room divider or be applied for exterior use. This trusted system, newly designed for flexible openings, allows for inward or outward folding. Its slender steel profiles and narrow face widths deliver robust, durable, and long-lasting folding partitions.
System description
Materials/Surface Finishes:
Strip-galvanised steel, suitable for powder coating or stove-enamellingElement Types:
Manual folding-sliding glass doors
2 to 6 leaves
Inward- and outward-opening options
Flexible leaf arrangement
performance characteristics
Equipment:
Fittings support up to 200 kg
Leaf weight up to 100 kg
Leaf widths up to 1,000 mm
Leaf heights up to 2,900 mmSpecial Technical Features:
Leaf installation depth: 60 mm
Frame installation depth: 60 mm
Infill elements: 13 – 37 mm
Face width from window overlap area: 105 mm
Face width (leaf with frame): 82.5 mm
Product details
Test Certificates:
CE marking in accordance with product standard EN 14351-1
Tightness against heavy rain: up to class 8A (450 Pa)
