Jansen has leveraged the benefits of ceramic materials to develop fire protection doors that combine exceptional strength with top-tier fire safety performance. The innovative fire-resistant infill enables the doors to achieve fire resistance ratings up to EI90, all within an element thickness of just 70 mm. The profiles are designed to seamlessly accommodate fittings, locks, and accessories.
System description
Materials / Surface Finishes
Uncoated steel or strip-galvanised steel, suitable for powder coating or stove-enamelling, with fire resistance up to EI90
Stainless steel 1.4401, available uncoated or polishedElement Types
Single and double doors, with or without side panels and transom windows
Partition walls
performance characteristics
Equipment
Steel and stainless steel hinges for welding or screw-fitting
Integrated door closers for EI60-rated doors
Multipoint locks (motorised options available)
Designer glazing beads
Emergency locks and panic push-barsSpecial Technical Features
Suitable for connection to solid or lightweight partition walls
Central glazed panel
Options for dry glazing or glazing with putty
Door heights up to 2.50 m with single-latch locks
Product details
Test Certificates
Fire resistance classes EI60 and EI90 tested in accordance with EN 1634-1 and DIN 4102-5
Special fire wall design certified for EI120
Smoke control compliant with DIN 18095
Smoke control tested as per EN 1634-3
Durability (C5) tested according to EN 1191
Emergency exit door standards met as per EN 1125 / EN 179
